Installation
9
Cut the non-adhesive foam
seal C strip to match the
window height. Insert the foam
seal between the glass and the
window frame to prevent air
and insects from getting into
the room.
If desired, install the security
bracket with 2 screws as shown.
Insert the window slider adapter
into the hole of the window slider.
Foam seal C
(Non-adhesive type)
2 Screws
Security
Bracket
Note: To ensure proper function, DO NOT overextend or bend the hose.
Make sure that there is no obstacle around the air outlet of the exhaust
hose (in the range of 500mm) in order to ensure the exhaust system works
properly. All the illustrations in this manual are for explanatory purposes
only. Your air conditioner may be slightly different. The actual shape
shall prevail.
To Next Page
