Unit Parts and Major Functions
2
Unit Parts
Fig. 2.1
Fig. 2.2
Unit Parts
And Major
Functions
Wall-mounted type
Duct / Ceiling type
Indoor unit
1. Panel frame
2. Rear air intake grille
3. Front panel
4. Air purifying lter & air lter (rear)
5. Horizontal louver
6. LCD display window
7. Vertical louver
8. Manual control button (behind)
9. Remote controller holder
Outdoor unit
10. Drain hose and refrigerant connecting pipe
11. Connective cable
12. Stop valve
13. Fan hood
Indoor unit
1. Air outlet
2. Air inlet
3. Air lter
4. Electric control cabinet
5. Wire controller
Outdoor unit
6. Drain hose and refrigerant connecting pipe
7. Connective cable
8. Stop valve
9. Fan hood
