Spares and Consumables
30 Dimple Grinder User’s Guide
7.0 Spares and Consumables
Spares
03368 Illuminator bulbs, x5
623.00082.0 Specimen mount for 15-mm wheel (Pyrex) x4
623.00084.0 Specimen mount for 15-mm wheel (stainless steel) x4
623.00152.0 Specimen mount for 20-mm wheel (Pyrex) x4
623.00154.0 Specimen mount for 20-mm wheel (stainless steel) x4
656.01050 Grinding wheel motor
656.01160 Specimen mount for 10-mm wheel (stainless steel) x4
656.01260 Grinding wheel clamping screw
656.01370 Drive coupling
656.01400 Centering ring, for use with 623-0008 specimen mount
656.01410 Centering ring, for use with short specimen mount (20-mm and
15-mm wheels)
656.01500 Grinding wheel bearing assembly
656.03100 PC board
656.03160 Turntable motor with gearbox
656.07061 Spherical grinding wheel, phosphor bronze, 10-mm wheel, x4
656.07062 Spherical grinding wheel, stainless steel, 10-mm wheel, x4
656.07063 Spherical grinding wheel, phosphor bronze, 15-mm wheel, x4
656.07064 Spherical grinding wheel, stainless steel, 15-mm wheel, x4
656.07065 Spherical grinding wheel, phosphor bronze, 20-mm wheel, x4
656.07066 Spherical grinding wheel, stainless steel, 20-mm wheel, x4
656.07350 Flat grinding wheel 15-mm only, phosphor bronze, x4
656.07511 Polishing wheel, 10-mm diameter, x4
656.07512 Polishing wheel, 15-mm diameter, x4
656.07513 Polishing wheel, 20-mm diameter, x4
Consumables
06527 Diamond polishing compound, 2–4 µm, 5-g syringe
06995 Cubic boron nitride (CBN) polishing compound, 0–2 µm, 5-g
syringe
06996 Cubic boron nitride (CBN) polishing compound, 4–6 µm, 5-g
syringe
623.01100.0 Mounting wax (12 rods, 3.5 mm x 32 mm)
656.04010 Alumina polishing suspension, 0.05 µm (2 oz)
656.07541 Felt polishing ring for 656.07511, 10-mm diameter, x15
656.07542 Felt polishing ring for 656.07512, 15-mm diameter, x15
656.07453 Felt polishing ring for 656.07513, 20-mm diameter, x15
