Thank you for purchasing the Gates Sonic tension
meter. Please read this manual thoroughly to fully
utilise all the meter’s functions.
CONTENTS PAGE
1. Important warnings ............................................. 3
2. Components of the 550C meter .........................3
3. Operating procedure for the 550C meter ..........4
4. Sonic tension meter operating theory ................ 6
5. Belt installation tension ...................................... 7
6. Tips on using the Sonic tension meter ............... 7
7. Meter recalibration for non-standard belts ........ 8
8. Summary of features ..........................................8
9. Optional accessories ..........................................8
10. Warranty and service ..........................................8
11. Belt unit weight calculation ................................8
550C
GATES SONIC TENSION METER MANUAL
