1. IMPORTANT WARNINGS!
Do not drop this unit. Impact of any
kind can result in damage.
Do not disassemble the unit.
Do not put the unit in a place where
fire or explosion is possible.
Do not put water, solvent or any
other liquids on this unit.
Do not leave this unit in a dusty environment.
Do not leave this unit where it will get hot,
such as in a car or in direct sunlight.
Do not use volatile solvents to clean this unit.
Do not use this in an area where
a spark could cause an explosion.
Do not bend the flexible arm sensor
(microphone) within 20 mm (3/4 inch) of
either end. Its construction is tubular, and
it should not be bent at sharp angles.
2. COMPONENTS OF
THE 550C METER
1 Flexible sensor
2 Sensor connector
3 Power switch
4 Belt unit weight key
5 Belt width key
6 Up button
7 Down button
8 Frequency range button
9 OLED screen with backlight
10 Measure key
11 Belt span length key
12 Frequency/tension display key
13 Data selection key
14 Batteries
550C
GATES SONIC TENSION METER MANUAL
