Gates 550C User Manual

9
GATES.COM
UKFDENLIPLRUCZ
Note:
Unit weights are for standard stock belts only.
Non-standard belt constructions may yield
inaccurate results and may require special unit
weights or special calibration procedures.
SYNCHRONOUS BELTS
Poly Chain
®
GT Carbon
™
(Volt*) (g/m)
5MGT 3.0
8MGT* 4.7
14MGT* 7.9
Poly Chain
®
GT2 (g/m)
8MGT 4.7
14MGT 7.9
PowerGrip
™
GTX (g/m)
8MX 5.8
14MX 9.7
PowerGrip
™
GT3 (g/m)
2MGT 1.4
3MGT 2.8
5MGT 4.1
PowerGrip
™
GT4 (g/m)
8MGT 4.9
14MGT 8.5
PowerGrip
™
HTD
™
(g/m)
3M 2.4
5M 3.9
8M 6.2
14M 9.9
20M 12.8
PowerGrip
™
(g/m)
MXL (0.080”) 1.3
XL (0.200”) 2.4
L (0.375”) 3.2
H (0.500”) 3.9
XH (0.875”) 11.3
XXH (1.250”) 14.9
Twin Power
™
(g/m)
PowerGrip
™
GT2
8MGT 6.9
14MGT 11.4
PowerGrip
™
HTD
™
5M 4.6
PowerGrip
™
XL 1.9
L 3.2
H 4.6
Long Length (g/m)
Poly Chain
®
GT Carbon
™
5MGT 3.0
8MGT 4.7
14MGT 7.9
PowerGrip
™
GT Steel Glass fibre
3MR - 3.01
5MR 4.50 4.50
8MR 6.44 6.44
PowerGrip
™
HTD
™
Steel Glass fibre
3M - 2.70
5M 3.90 3.90
8M 6.20 6.20
14M 9.90 9.90
PowerGrip
™
Steel Glass fibre
XL - 2.32
L - 3.16
H 4.30 4.30
Synchro-Power
™
Steel Aramid
T5 2.2 2.0
T10 4.4 3.6
T10HF 4.7 -
T20 7.5 5.9
AT5 3.3 2.7
AT10 5.7 4.2
550C
GATES SONIC TENSION METER MANUAL
