Using Your Gateway Flat-Panel Monitor
6
4 Plug the speaker bar’s power and audio plugs into the appropriate connectors underneath
the monitor.
5 Plug the speaker bar’s pink and green 3.5 audio plugs into the appropriate speaker and
microphone connectors on the computer.
For information on using the speaker bar, see “Using the speaker bar” on page 18.
To remove the speaker bar:
1 Disconnect all audio and power cables from the speaker bar.
2 Press the two clips on the back of your monitor, then slide the speaker bar back.
Important
For best audio performance, if your video connection uses HDMI, the digital
audio is also conveyed along the same cable, and no additional audio connection is
required. You may need to set your video source’s audio mode to PCM or ANALOG
to hear the audio. See your source device’s user guide for more information.
Power
connector
Audio jack
Mounting clip
