Using Your Gateway Flat-Panel Monitor
2
Connecting the monitor
To set up the monitor, first attach the base, then make your cable connections.
Attaching the stand
To attach the stand:
1 Place the monitor face-down on a soft, non-marring surface. A non-slip mat on a tabletop
is ideal.
2 Remove the four thumbscrews that are attached to the back of the monitor.
3 Lay the stand on the monitor so the thumbscrew holes line up with the holes in the stand.
4 Replace the thumbscrews.
5 Test the bracket connection to make sure it is secure, then place the monitor upright.
Connecting video inputs
To connect video sources to your monitor:
1 Position your computer and the monitor so you can reach the back of each.
2 Make sure that you computer is turned off.
Tip
Rotate the screen 90° to make it easier to connect the cables.
Thumbscrew
Thumbscrew
Thumbscrew
Thumbscrew
