www.gateway.com
5
2 Connect any USB device to one of the available USB 2.0 ports on the left side or back of the
monitor.
Setting up the optional speaker bar
An optional speaker bar is available for mounting underneath your monitor. You can order a
speaker bar from www.gateway.com.
To install the speaker bar:
1 Turn off the monitor.
2 Tilt the screen back, then match the mounting clips on each side of the speaker bar with
the mounting slots underneath the monitor.
3 Slide the speaker bar onto the bottom of the monitor until it snaps into place. Make sure
that it is secure by pulling it downward.
Important
If you connect the speaker bar to the monitor while the monitor is turned on,
the speaker bar will not initialize and will not work correctly. If this happens, turn
the monitor off, then back on to enable the speaker bar.
USB ports
Mounting clip
Mounting slot
