Gateway FPD1510 - SPECIFICATIONS; LCD CHARACTERISTICS; OPTICAL CHARACTERISTICS; SIGNAL

CONTENTS
SPECIFICATIONS
- 2 -
1. LCD CHARACTERISTICS
Type : TFT Color LCD Module
Size : 352.0(H) x 263.5(V) x 14.0(T)
Pixel Pitch : 0.300mm x 0.300mm
Color Depth : 16,2M colors
Active Video Area : 15.1inch
(307.2mm x 230.4mm diagonal)
Surface Treatment : Anti-Glare, Hard Coating (3H)
Backlight Unit : Two-CCFL (Cold Cathode
Fluorescent Lamp)
2. OPTICAL CHARACTERISTICS
2-1. Viewing Angle by Contrast Ratio
≥ 10
Left : 60° typ., 60° min.
Right : 60° typ., 60° min.
Top : 45° typ., 45° min.
Bottom : 45° typ., 45° min.
2-2. Luminance : 250 cd/m
2
typ.
2-3. Contrast Ratio : 300 typ.
3. SIGNAL (Refer to the Timing Chart)
3-1. Sync Signal
1) Type : Separate Sync. (Horizontal & Vertical)
2) Input Voltage Level: Low=0~0.8V, High=2.1~5.5V
3) Sync Polarity : Positive or Negative
3-2. Video Input Signal
1) Type : R, G, B Analog
2) Voltage Level : 0~0.714 V
a) Color 0, 0 : 0 Vp-p
b) Color 7, 0 : 0.467 Vp-p
c) Color 15, 0 : 0.714 Vp-p
3) Input Impedance : 75 Ω
3-3. Operating Frequency
Horizontal : 31 ~ 61kHz
Vertical : 56 ~ 75Hz
4. POWER SUPPLY
4-1. Power Adaptor
Input : AC 100~240V, 50/60Hz 1.2A
Output : DC 12V 3.0A
4-2. Power Consumption
5. ENVIRONMENT
5-1. Operating Temperature: 10°C~35°C (50°F~95°F)
(Ambient)
5-2. Relative Humidity : 10%~80%
(Non-condensing)
5-3. MTBF : 50,000 Hours (Min.)
6. DIMENSIONS (with TILT/SWIVEL)
Width : 389mm (15.3'')
Depth : 205mm (8.1'')
Height : 392mm (15.4'')
7. WEIGHT (with TILT/SWIVEL)
Net. Weight : 4.8kg (10.6 lbs)
Gross Weight : 7.0kg (15.4 lbs)
SPECIFICATIONS ................................................... 2
PRECAUTIONS ....................................................... 3
TIMING CHART ....................................................... 4
OPERATING INSTRUCTIONS ................................ 5
WIRING DIAGRAM ................................................. 6
DISASSEMBLY ....................................................... 7
BLOCK DIAGRAM ................................................... 9
DESCRIPTION OF BLOCK DIAGRAM....................11
ADJUSTMENT ...................................................... 12
TROUBLESHOOTING GUIDE .............................. 13
PRINTED CIRCUIT BOARD................................... 17
EXPLODED VIEW...................................................19
REPLACEMENT PARTS LIST ...............................21
PIN CONFIGURATION............................................25
SCHEMATIC DIAGRAM......................................... 28
PACKING AND ACCESSORIES..............................32
MODE
POWER ON (NORMAL)
STAND-BY
SUSPEND
DPM OFF
POWER OFF
H/V SYNC
ON/ON
OFF/ON
ON/OFF
OFF/OFF
-
POWER CONSUMPTION
less than 30 W
less than 5 W
less than 5 W
less than 5 W
less than 5 W
LED COLOR
GREEN
AMBER
AMBER
AMBER
OFF
VIDEO
ACTIVE
OFF
OFF
OFF
-
