- 27 -
EZ1086 1.5AMP POSITIVE VOLATAGE REGULATOR
TO-220
TO-263
123 1
PIN
1
FUNCTION
ADJ/GND
2
OUTPUT
3
TAB IS OUTPUT
INPUT
23
Pin Configuration
BLOCK DIAGRAM
PARTSTYPE
PARTSTYPE
BA033FP
1. Vcc
2. GND
3. OUT
1
3
2
ICs
Transistor
KIA7042F
1
3
2
1: Vcc
2: GND
3: OUT
