MODEL: FPD1810 DATE: 2001. 7. 30.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
L403 6210TCE001G HH-1M3216-501 CERATEC 3216MM R/
L701 6210TCT002B ACB2012M-300-T TDK , CHIP BEAD,
L702 6210TCT002B ACB2012M-300-T TDK , CHIP BEAD,
L703 6210TCE001G HH-1M3216-501 CERATEC 3216MM R/
L704 6210TCE001C HB-1T3216-500JT CERATEC 3216MM
L705 6210TCE001C HB-1T3216-500JT CERATEC 3216MM
L707 6210TCE001C HB-1T3216-500JT CERATEC 3216MM
L708 6210TCE001C HB-1T3216-500JT CERATEC 3216MM
L709 6210TCE001D HB-1M2012-601JT CERATEC 2012MM
L801 6140TBZ015E DR10*10 150UH 0.35MM 41.5T BA15
L802 6210TCE001G HH-1M3216-501 CERATEC 3216MM R/
L803 6210TCE001G HH-1M3216-501 CERATEC 3216MM R/
L804 6210TCE001C HB-1T3216-500JT CERATEC 3216MM
L805 6210TCE001C HB-1T3216-500JT CERATEC 3216MM
L810 6210TCE001G HH-1M3216-501 CERATEC 3216MM R/
L811 6210TCE001G HH-1M3216-501 CERATEC 3216MM R/
Q501 0IKE704200J KIA7042AF SOT-89 TP 4.2V VOLTAG
Q701 0TR390409AE KST3904-MTF TP SAMSUNG SOT23 GE
Q702 0TR390409AE KST3904-MTF TP SAMSUNG SOT23 GE
R130 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R201 0RJ2001D677 2K OHM 1/10 W 5% 1608 R/TP
R202 0RJ2001D677 2K OHM 1/10 W 5% 1608 R/TP
R203 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R204 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R205 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R206 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R207 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R208 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R209 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R210 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R211 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R212 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R213 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R214 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R215 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R216 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R218 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R219 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R220 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R221 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R222 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R223 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R224 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R225 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R227 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R229 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R231 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R233 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R234 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R235 0RH2201D622 2.2K 1/10W P-TYPE TAPPING
R236 0RJ0122D677 12 OHM 1/10 W 5% 1608 R/TP
R237 0RJ0122D677 12 OHM 1/10 W 5% 1608 R/TP
R238 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R239 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R240 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R241 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
MODEL: FPD1810 DATE: 2001. 7. 30.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R242 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R243 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R401 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R402 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R403 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R404 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R406 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R501 0RJ1004D677 1000000 OHM 1/10 W 5% 1608 R/TP
R502 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R508 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R509 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R510 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R511 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R512 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R513 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R516 0RH2200D622 220 1/10W 5 D.R/TP
R518 0RH2200D622 220 1/10W 5 D.R/TP
R519 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R522 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R523 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R524 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R525 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R526 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R527 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R528 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R529 0RJ7502D677 75K OHM 1/10 W 5% 1608 R/TP
R531 0RJ3302D677 33K OHM 1/10 W 5% 1608 R/TP
R532 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R533 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R534 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R535 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R536 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R537 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R538 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R539 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R542 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R543 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R544 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R545 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R548 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R549 0RJ1000D677 100 OHM 1/10 W 5% 1608 R/TP
R550 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R551 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R560 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R580 0RJ4700D677 470 OHM 1/10 W 5% 1608 R/TP
R701 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R703 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R704 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R705 0RJ0752D677 75 OHM 1/10 W 5% 1608 R/TP
R706 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R707 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R708 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R709 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R710 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R713 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R714 0RJ1801D677 1.8K OHM 1/10 W 5% 1608 R/TP
R715 0RJ1002D677 10K OHM 1/10 W 5% 1608 R/TP
R716 0RJ0472D677 47 OHM 1/10 W 5% 1608 R/TP
R717 0RJ4701D677 4.7K OHM 1/10 W 5% 1608 R/TP
R718 0RJ0122D677 12 OHM 1/10 W 5% 1608 R/TP
R719 0RJ0122D677 12 OHM 1/10 W 5% 1608 R/TP
R720 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
- 24 -
TRANSISTOR
RESISTORs
