MODEL: FPD1810 DATE: 2001. 7. 30.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R721 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R722 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R723 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R724 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R725 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R729 0RJ1001D677 1K OHM 1/10 W 5% 1608 R/TP
R730 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R731 0RJ0000D677 0 OHM 1/10 W 5% 1608 R/TP
R801 0RJ3602D677 36K OHM 1/10 W 5% 1608 R/TP
R802 0RJ3602D677 36K OHM 1/10 W 5% 1608 R/TP
R803 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R804 0RJ9101D677 9.1K OHM 1/10 W 5% 1608 R/TP
R805 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R806 0RJ1003D677 100K OHM 1/10 W 5% 1608 R/TP
R809 0RJ2202D677 22K OHM 1/10 W 5% 1608 R/TP
R810 0RJ1500D677 150 OHM 1/10 W 5% 1608 R/TP
R820 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R821 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R822 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R823 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R824 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R825 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R826 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R827 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R828 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
R829 0RJ0222D677 22 OHM 1/10 W 5% 1608 R/TP
RA202 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA204 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA206 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA208 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA210 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA212 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA214 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA216 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA218 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA220 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA222 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA224 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA225 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA226 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA227 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA228 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA229 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA230 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA231 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA232 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA233 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA234 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA235 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA236 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA237 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA238 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA239 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA240 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA241 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
RA242 0RHZTCZ001D 22 OHM 1/16 W 5% 3215 R/TP
J801 6612TAH003A DJ-023 KSD R/ANGLE LB563B
X201 6202TST001E SX-1 SUNNY CHIP 24MHZ 30PPM 20P
X501 6202TST001E SX-1 SUNNY CHIP 24MHZ 30PPM 20P
MODEL: FPD1810 DATE: 2001. 7. 30.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C1 0CN1040K949 0.1M 50V Z F TA52
C2 0CN1040K949 0.1M 50V Z F TA52
C3 0CN1040K949 0.1M 50V Z F TA52
R1 0RD4701Q609 4.70K 1/4W(3 5% TA52
R2 0RD4701Q609 4.70K 1/4W(3 5% TA52
R3 0RD8200Q609 820 1/4W(3 5% TA52
R4 0RD8200Q609 820 1/4W(3 5% TA52
R5 0RD1501Q609 1.50K 1/4W(3 5% TA52
R6 0RD1501Q609 1.50K 1/4W(3 5% TA52
R7 0RD2201Q609 2.20K 1/4W(3 5% TA52
SW1 140-058D SKHV10911A LGEC NON 12 20 HORIZ
SW2 140-058D SKHV10911A LGEC NON 12 20 HORIZ
SW3 140-058D SKHV10911A LGEC NON 12 20 HORIZ
SW4 140-058D SKHV10911A LGEC NON 12 20 HORIZ
SW5 140-058D SKHV10911A LGEC NON 12 20 HORIZ
SW6 140-058D SKHV10911A LGEC NON 12 20 HORIZ
SW8 140-058E SKHV10910B LGEC NON 12V 20A HOR
ZD1 0DZ560009CE MTZJ5.6B TP ROHM-K DO34 500MW
ZD2 0DZ560009CE MTZJ5.6B TP ROHM-K DO34 500MW
J1 6602T20009E SMAW200-06 YEONHO 2.0MM LOCK R/
LED2 0DL305029BA LTL-305DJ-0C2 TP LITEON GREEN/Y
LCD 6304FLP003A LM181E04-B3 LG PHILPS TFT COLOR
C/ASS’Y 6631T11012K 31P H-H 95MM UL20276 UNIXTAR LG
INVERTER
6633TZA004E SAMSUNG LG1805 LG883D
AC-DC/A
6634TBZ006M PSCV700101A SAMSUNG 12V 5.8A FO
D-SUB/CABLE
6866TD9001L UL 2990-9C(7.5) DT 1870MM COOL
DVI/CABLE
6866TDV004F UL20276 DT 2000MM PEARL WH LG56
- 25 -
MISCELLANEOUS
OTHERs
CONTROL BOARD
