10 - Quick start guide
BASE VIEW
# Icon Item Description
1
Ventilation and
cooling fan
Allows the computer to stay cool.
- Do not cover or obstruct the openings.
2
Memory
compartment
Houses the computer's main memory.
Hard disk bay
Houses the computer's hard disk (secured with
screws).
3 Battery release latch
Releases the battery for removal. Insert a
suitable tool and slide to release.
4 Battery bay Houses the computer's battery pack.
5 Battery lock Locks the battery in position.
6 Speakers Deliver stereo audio output.
1
2
3
4
5
6
