22 - Getting to know your computer
LEFT VIEW
# Icon Item Description
1 DC-in jack Connects to your computer’s AC adapter.
2 Ethernet (RJ-45) port
Connects to an Ethernet 10/100/1000-based
network.
3
Ventilation and
cooling fan
Allows the computer to stay cool.
- Do not cover or obstruct the openings.
4
External display
(VGA) port
Connects to a display device (e.g., external
monitor, LCD projector).
5 HDMI port
Supports high-definition digital video
connections.
6 USB port
Connects to USB devices.
- If a port is black, it is USB 2.0 compatible, if
it is blue it is also USB 3.0 compatible (see
below).

Gateway NE56R Specifications

General

Operating System	Windows 8
Storage	750GB HDD
Display	15.6-inch HD (1366x768)
Graphics	Intel HD Graphics
Battery	6-cell Li-ion
Weight	2.5 kg (5.51 lbs)
Dimensions	381 x 253 x 33.2 mm (15 x 9.96 x 1.31 inches)
Processor	Intel Pentium B960
