GAUI X3 - Main Rotor Head Assembly

Insert 2x8 and M2x12 screws thru the side
frames and boom clamp but do not tighten yet,
wait until step in P.22 where the boom in installed
and adjusted before tightening these screws.
將 2x8跟M2x12穿過碳纖側板並鎖入管夾組，
不鎖緊待P.22組裝尾管時一並鎖緊固定。
2x8
M2x12
4
P.8
Frame assembly
機體組裝
2x8
#821608
x8 pcs
M2x12
#842012
x1 pcs
#216141
1
1
1
#216151
2
2
8.0
12.00
