GAUI X3 - Electronics Installation

17
P.22
Tail boom assembly
尾管組裝
2x5
#821605
2x5
W2x5x0.5
2x14
M2x10
x1 pcs
2x14
x2 pcs
18
#216131
2
1
#216161
4
#216210
1
3
#216254
3
4
2
#821614
14.0
5.0
W2x5x0.5
x2 pcs
#216208
Coordinate with P.8 about installation of tail boom and
tightening 2x8 and M2x12 locking screw.
Use adjustment washers to avoid screw interfering with
the torque tube collar.
配合P.8組裝尾管後鎖緊 2x8夾持螺絲M2x12定位螺絲。
調整墊片厚度避免螺絲干涉固定環。
M2x10
#842009
x2 pcs
10.0
