2
P.2
Main shaft mounts assembly
主軸板組裝
2x8
#821608
2x8
2x5
x6 pcs
2x5
#821605
1
#216253
1
8.0
N2x4
#884001
x3 pcsx4 pcs
13.5 mm
N2x4
5.0
建議球頭安裝參考距離。
Recommended ball head screw
installation distance.
