M3x5___________
4
M3x8___________
1
M3x8
M3x10
M3x10
M3x12
M3x5
M3x5
M3x5
M3x5
M3x10__________
2
機體側板組裝(左)-4
機體側板組裝(左)-5
陀螺儀鋁板
螺絲均需上止滑劑
All Screws on side plates should
be applied with thread lock.
螺絲均需上止滑劑
All Screws on side plates should
be applied with thread lock.
M3x12__________
1
圓鋁柱(26.4mm)
CNC隔板組(A型)
後腳板組
組裝(艙罩支柱A型)時先將M3x12螺絲鎖入支柱內，
在使用直徑2以下的圓棒插入孔內並旋緊艙罩支柱。
Main Frame Assembly (Left)-4
Main Frame Assembly (Left)-5
CF back brace set
Frame post(26.4mm)
Gyro mounting plate
CNC divider plate
(Type A)
When assembling the canopy posts, x the M3x12
screw inside the post, use a stick as tool to tighten
the canopy posts.
螺絲墊片
Countersunk Washer
