GB Instruments Wire-Tracker GET-4110K, LAN-Tracker GET-4220K User Manual

7
Trace the wiring as described above.
You may notice that the receiver must
be contacting the LAN wire and is
stronger along one side of the wire.
This is normal and is due to the
physical properties of the LAN cable,
which is designed to prevent
interference from external signals.
Make sure all wiring is
disconnected from any
power source.
To trace a single wire, connect the red
lead alligator clip to the wire to be
traced. To boost the signal, connect
the black lead alligator clip to a
suitable ground. Two wires can be
traced at the same time by connecting
one alligator clip to each wire;
however, the signal will not be as
strong as it is while tracing a single
wire with the black alligator clip
connected to ground. Trace the wiring
as described above.
Tracing Other Unenergized
Wiring
!
WARNING
