GBC CombBind C110E User Manual

Please read these instructions carefully and keep them in a safe place for later reference.
Instructions for use
Binding
1
To turn the machine “ON” press the ON / OFF (I/O) switch
located in the rear of the machine. A green light will
illuminate to indicate that the power is on.
2
Place the document including the covers straight up against
the comb support to the right side aligning with the binding
size scale. Rotate the binding lever away from you to close
the hooks until they make contact with the document.
3
Select comb which fits your document (fig.3)
Use the comb size guide to select the size of comb that fits
your document i.e. 25 sheet document = 6mm comb.
4
Load comb onto machine (fig.4)
Insert the binding comb next to the white positional arrow
on the machine, behind the metal comb support fingers,
with the open side of the comb pointing upwards.
Note: If using GBC ProCombs™ the coloured line on your
comb should align to the coloured arrows on the machine
for faster binding.
5
Open comb by turning lever towards you
The coloured arrows adjacent to the opening comb act as
a guide as to how far to open in order to allow punched
sheets to be easily inserted.
Rotate the binding handle towards you to open the hooks
away from the comb support (fig.6)
6
Jog or align the sheets or covers and insert the edge to be
punched into the punch throat opening.
7
Fully insert the sheets into the throat opening and against
the edge guide (fig.5).
8
To punch, press the punch button
(fig.5). The
CombBind C110 E will punch up to 15 sheets of 80 gsm
paper. Do not punch more than 1 clear cover at a time to
prevent jams.
9
If the punch jams the red jam light
will illuminate to
indicate that the machine has jammed. The machine will
automatically reverse the punches to clear the jam and the
red jam light will remain illuminated. Remove the paper
and push the punch button to re-set the machine. The red
jam light will turn off indicating that the machine is ready to
punch. Reduce some of the sheets and repeat steps 2 to 4
to avoid jams on additional lifts.
J
Place the front cover (finished side down) onto the opened
binding element fingers. Place the document pages (face
down) onto the element. Repeat for larger documents as
required. Place the back cover (finished side up) on the
open binding element fingers last.
K
Rotate the binding lever away from you, back to its original
position to close the binding element.
L
Remove the book by lifting upward. Your document is now
complete.
M
Once you become familiar with your CombBind C110 E you
will find that you can bind as you punch, increasing your
productivity.
N
When finished punching turn the machine OFF by pressing
the ON / OFF (I/O) switch located at the rear of the machine.
Determine sheet width
• Rotate the edge guide to the paper / cover size you wish to
bind (fig.1):
- Letter (8-1/2" x 11")
- A4 (297mm x 210mm)
- Oversized (222mm x 286mm)
• When using oversized covers, rotate the edge guide to the
oversize position, punch all of the covers for your documents
and set aside.
• Rotate the edge guide to either Letter or A4 position and
punch the paper for your document.
Getting started
Plug the power cord into an appropriate power receptacle.
6

GBC CombBind C110E Specifications

General

Format	A4
Control type	Buttons
Product color	Black
LED indicators	Stand-by
Punch capacity	15 sheets
Binding capacity	330 sheets
Country of origin	China
Method of control	Electric
Maximum paper width	38 mm
Anti-blocking system	Yes
Punch holes quantity	21

Weight and Dimensions

Depth	385 mm
Width	350 mm
Height	220 mm
Package depth	301 mm
Package width	490 mm
Package height	435 mm
