separation between the pre-existing and newly installed film requires that the
motor be immediately stopped and the situation corrected to assure that the
pre-existing and new films are passed through concurrently.
19. Set the motor RUN/STOP switch to the "Stop” position once the installed
film is completely exiting the laminator.
20. Check film alignment. See section entitled Film Alignment Proceduj:e for
instructions if installed film needs alignment.
FILM ALIGNMENT PROCEDURE
Review alignment of left and right edges of the top and bottom film rolls. Set
the ON/STANDBY switch to the “Standby” 0 position if re-alignment is
necessary. Adjust alignment by repositioning the metal disc on either film
supply roll shaft. Use the alien wrench (3/32 in.) supplied with the laminator
to loosen the set screw of either metal disk. Slide the disc and the film roll
along the shaft until they are aligned with the film roll on the other shaft. Lock
the disc into position by tightening the loosened set screw with the alien
wrench.
FEED TABLE REMOVAL
Refer to figure 2 and the following procedure to remove the feed table:
1. Lift the shield to its upright position.
2. Slide the Feed Table Latch to the right.
3. Lift the table upwards and away from the laminator.
OPERATING PROCEDURE
The speed setting may be positioned at the “Fast” setting when the laminator
will be used within a short period of time. To conserve energy, the speed
setting may be positioned at “Slow” when it is expected the laminator will not
be used for longer periods of time. It is recommended the ON/STANDBY
switch be set at the Standby Ci) when not operated for long periods of time.
1. Lower the Safety Shield to its full down position.
2. Check that the Feed Table latch is penetrating the left hand side plate.
