MODE SELECTION
Using the mode selection dip-switches select the desired operating modes. Note the times associated with the
parameters marked with an * can be changed. The auto-close times can be changed using the procedure in the
following section. See the detailed installation manual for details on how to change the other parameters.
POSITION 2 Pulse Lock Output
OFF - Lock output is activated for the entire motor drive cycle.
ON - Lock output pulses for 0.3 seconds* at the start of each drive cycle.
POSITION 3 Light Outputs Warning
OFF - Optional light module controls a light with timer which turns light off after 60seconds*.
ON - Optional light module controls a warning light which activates whenever motors are on.
POSITION 4 Swipe Mode (OSC Input)
OFF - OSC input terminal has standard Open, Close, Stop action.
ON - OSC input terminal will only open the door/gate. The input also resets the P.E triggered auto-close
mode so that the P.E input will need to be triggered again before a P.E auto- close cycle will be initiated.
POSITION 5 M 2 Outputs Status
OFF - The M2 output controls second motor
ON - The M2 output controls status lights
POSITION 6 P.E Stops Close Cycle
OFF - Activating the P.E input while motors are closing causes the motors to reverse.
ON - Activating the P.E input while motors are closing causes the motors to stop but not reverse.
POSITION 7 P.E Stops Open Cycle
OFF - Activating the P.E input while motors are opening is ignored by the controller.
ON - Activating the P.E input while motors are opening causes the motors to stop.
POSITION 8 P.E Triggered Auto Close
OFF - Not selected
ON - Selects the P.E triggered auto-close mode which causes the motors to auto-close if the P.E input is activated
then released. (Auto-close delay time is 0 seconds*)
POSITION 9 Pedestrian Auto-Close
OFF - No pedestrian access auto-close
ON - Selects auto-close in the pedestrian access mode. (Auto-close delay time is 15 seconds*)
POSITION 10 Standard Auto Close
OFF - Not selected
ON - Selects standard auto-close mode which will close the motors after fully opening.(Auto-close delay time is 30
seconds*)
