INSTALLATION
2-7
Table 2-1 - Terminal Identification
Terminal Function
1 Ext. Switch #1 "+"
2 Ext. Switch #2 "+"
3 Ext. Switch #3 "+"
4 Ext. Switch #4 "+"
5 Ext. Switch #5 "+"
6 Ext. Switch #6 "+"
7 Ext. Switch #7 "+"
8 Ext. Switch #8 "+"
9 Breaker Open (52b) "+"
10 Breaker Common "–"
11 Breaker Closed (52a) "+"
12 Reclosure Enable "+"
13 Reclosure Common "–"
14 Reclosure Disable "+"
15 Block TC Common
16 Block TC N.O.
17 Analog Out "-"
18 Analog Out "+"
19 Analog Select A
20 Analog Select B
21 Analog Select C
22 Analog Select D
23 Analog In "-"
24 Analog In "+"
25 Trip Relay N.C.
26 Remote Trip "+"
27 Remote Common "-"
28 Remote Close "+"
29 Block TC N.C.
575 only
30 ** Aux 4 Relay N.O.
31 ** Aux 4 Relay Common
32 ** Aux 4 Relay N.C.
33 ** Access Switch "+"
34 ** Access Switch "-"
35 Voltage Input V1
36 Voltage Input V2
37 Voltage Input V3
38 Voltage Input Vn
39 43 Remote "+"
40 43 Remote "-"
41 Trip Relay N.O.
42 Close Relay Contact 1
43 Aux 1 Relay N.O.
44 Aux 2 Relay N.O.
45 Aux 3 Relay N.C.
46 Aux 1 Relay N.C.
47 Aux 2 Relay N.C.
48 Aux 3 Relay N.O.
49 Phase 1 Common
50 Phase 1 Input :5/:1
51 Phase 2 Common
52 Phase 2 Input :5/:1
53 Phase 3 Common
54 Phase 3 Input :5/:1
55 Ground Current Common
56 Ground Current Input :5/:1
57 Trip Relay Common
58 Close Relay Contact 2
59 Aux 1 Relay Common
60 Aux 2 Relay Common
61 Aux 3 Relay Common
62 Control Voltage GND
63 Supply Voltage "+"
64 Supply Voltage "-"
65 RS485 Port "+"
66 RS485 Port "-"
67 MTM/RS485 Shield
68 ** MTM RS485 "+"
69 ** MTM RS485 "-"
70 IRIG-B
575 only
71 Analog Select Common
72 Ext. Switch Common
** 565 requires Option Card
Terminal Function
}
575 only
