4-3
Location Message Line Description
A 1.1
ACTUAL VALUES
CURRENT
The actual values page 1 header. This page gives information on the
feeder phase and ground currents being monitored by the 565 Relay.
A 1.2
PHASE A CURRENT
710 A
This is the actual monitored RMS current flowing in phase A of the feeder.
A 1.3
PHASE B CURRENT
715 A
This is the actual monitored RMS current flowing in phase B of the feeder..
A 1.4
PHASE C CURRENT
710 A
This is the actual monitored RMS current flowing in phase C of the feeder.
Message A 1.5 will only appear if Ground Sensing has been enabled in setpoints.
A 1.5
GROUND CURRENT
10 A
This is the actual leakage current flowing to ground in the system.
A 1.6
PHASES A= 710
B= 715 C= 710
This message allows all three phase currents to be displayed if they are
greater than 2% CT.
PHASES A<2% CT
B<2% CT C<2% CT
When the breaker is closed and the current is less than 2% of CT, the three
phase display will reflect this with “<2% CT”.
A 1.7
CURRENT
END OF PAGE
The last line of page 1, actual values. Press the PAGE key to view page 2.
ACTUAL VALUES MODE - CURRENT
