4-4
Location Message Line Description
A 2.1
ACTUAL VALUES
ANALOG INPUT
The actual values page 2 header. The 565/575 Relay can accept an analog
signal from 4 to 20 mA from any device such as a temperature monitor,
and provide trip or alarm signals at a user programmed value. The value of
this temperature, for example, is displayed in this page in whatever units
you select in the setpoints mode. Degrees Celsius are shown.
Message A 2.2 will only appear if Analog-In has been disabled in setpoints.
A 2.2
ANALOG INPUT
DISABLED
If Analog-In has been disabled in setpoints, this will be the only message
displayed.
Message A 2.3 will only appear if Analog In has been enabled in setpoints.
A 2.3
TRANS WNDG TEMP
87 DEG C
This is the present value of the analog signal being monitored by the Relay,
if this option is used. In this example, the temperature of a transformer
winding is being monitored and degrees Celsius units have been chosen.
Other names and units can be selected, in setpoints mode.
A 2.4
ANALOG INPUT
END OF PAGE
The last line of page 2. Press the PAGE key to view page 3.
L
A
ACTUAL VALUES MODE - ANALOG INPUT
