FEATURE INFORMATION
565/575 MEMORY MAP (REVISION E2.73)
ADDRESS GROUP DESCRIPTION RANGE STEP UNITS SCALE FORMAT FACTORY
(DEC) (HEX) CODE DEFAULT
Actual Values - READ ONLY
0444 01BC SWITCH NUMBER 4 STATUS 0 or 1 - - - F28 0
0471 01D7 SWITCH NUMBER 5 STATUS 0 or 1 - - - F28 0
0472 01D8 SWITCH NUMBER 6 STATUS 0 or 1 - - - F28 0
0473 01D9 SWITCH NUMBER 7 STATUS 0 or 1 - - - F28 0
0474 01DA SWITCH NUMBER 8 STATUS 0 or 1 - - - F28 0
0445 01BD BREAKER OPEN STATUS 0 or 1 - - - F37 0
0446 01BE BREAKER CLOSED STATUS 0 or 1 - - - F37 0
0447 01BF ANALOG SELECT A STATUS 0 or 1 - - - F38 0
0448 01C0 ANALOG SELECT B STATUS 0 or 1 - - - F38 0
0449 01C1 ANALOG SELECT C STATUS 0 or 1 - - - F38 0
0450 01C2 ANALOG SELECT D STATUS 0 or 1 - - - F38 0
0451 01C3 ACCESS JUMPER STATUS 0 or 1 - - - F20 1
0452 01C4 REMOTE/LOCAL 43 STATUS 0 or 1 - - - F39 0
0453 01C5 RESERVED
:: :
0454 01C6 RESERVED
0455 01C7 (575 Only) RECLOSE ENABLE STATUS 0 or 1 - - - F37 0
0456 01C8 (575 Only) RECLOSE DISABLE STATUS 0 or 1 - - - F37 1
0457 01C9 RESERVED
:: :
0459 01CB RESERVED
0460 01CC LCD DISPLAY CONTRAST 0 - 10 1 - 1.00 F14 5
0461 01CD SOFTWARE RELEASE DATE - - - - F13 Mar 12, 1996
0463 01CF RESERVED
0464 01D0 FACTORY SERVICE ANALOG OUTPUT FORCED TO 0 - 255 1 - 1.00 F14 0
0465 01D1 RESERVED
0466 01D2 TEST LCD DISPLAY? (RESERVED)
0467 01D3 RESERVED
0468 01D4 LOAD FACTORY SETTINGS (RESERVED)
0469 01D5 CAL. ANALOG IN AT 4 mA (RESERVED)
0470 01D6 CAL. ANALOG IN AT 20 mA (RESERVED)
0471 01D7 SEE SETPOINTS CALIBRATION MODE GROUP
:: :
0474 01DA SEE SETPOINTS CALIBRATION MODE GROUP
0475 01DB RESERVED
:: :
0489 01E9 RESERVED
0490 01EA VOLTAGE VT CONNECTION 0 - 3 - - - F40 1
0491 01EB VT NOMINAL SEC VOLTS 48.0 - 240.0 0.1 VOLTS 0.10 F14 120.0
0492 01EC VT PRIMARY VOLTS 0.10 - 138.00 0.01 kV 0.01 F14 1.20
0615 0267 ZERO VOLTS DETECT 0 or 1 - - - F20 1
0493 01ED UNDERVOLT TRIP 0 or 1 - - - F20 1
0494 01EE UNDERVOLT TRIP LEVEL 50 - 100 1 %VT 1.00 F14 80
0495 01EF UNDERVOLT TRIP DELAY 0.1 - 25.5 0.1 SEC 0.10 F14 1.0
0496 01F0 UNDERVOLT TRIP RELAY 0 - 6 - - - F22 3 (565), 1 (575)
0497 01F1 UNDERVOLT ALARM 0 or 1 - - - F20 1
0498 01F2 UNDERVOLT ALARM LEVEL 50 - 100 1 %VT 1.00 F14 85
0499 01F3 UNDERVOLT ALARM DELAY 0.1 - 25.5 0.1 SEC 0.10 F14 1.0
0500 01F4 UNDERVOLT ALARM RELAY 0 - 3 - - - F23 1 (565), 2 (575)
0501 01F5 OVERVOLT TRIP 0 or 1 - - - F20 1
0502 01F6 OVERVOLT TRIP LEVEL 101 - 125 1 %VT 1.00 F14 120
0503 01F7 OVERVOLT TRIP DELAY 0.1 - 25.5 0.1 SEC 0.10 F14 1.0
0504 01F8 OVERVOLT TRIP RELAY 0 - 6 - - - F22 0 (565), 1 (575)
0505 01F9 OVERVOLT ALARM 0 or 1 - - - F20 1
0506 01FA OVERVOLT ALARM LEVEL 101 - 125 1 %VT 1.00 F14 115
0507 01FB OVERVOLT ALARM DELAY 0.1 - 25.5 0.1 SEC 0.10 F14 1.0
0508 01FC OVERVOLT ALARM RELAY 0 - 3 - - - F23 0
0509 01FD RESERVED
:: :
0519 0207 RESERVED
0520 0208 DEMAND METERING AMPS DEMAND 0 or 1 - - - F20 0
0521 0209 AMPS DEMAND TIME PERIOD 5 - 120 1 MIN 1.00 F14 5
0522 020A AMPS DEMAND ALARM 0 or 1 - - - F20 1
0523 020B AMP DEMAND ALARM LEVEL 10 - 5000 5 AMPS 1.00 F14 100
0524 020C AMP DEMAND ALARM RELAY 0 - 3 - - - F23 0 (565), 2 (575)
0525 020D KW DEMAND 0 or 1 - - - F20 0
0526 020E KW DEMAND TIME PERIOD 5 - 120 1 MIN 1.00 F14 5
0527 020F KW DEMAND ALARM 0 or 1 - - - F20 1
0528 0210 KW DEMAND ALARM LEVEL 100 - 65000 100 kW 1.00 F14 1000
0529 0211 KW DEMAND ALARM RELAY 0 - 3 - - - F23 0 (565), 2 (575)
0530 0212 KVAR DEMAND 0 or 1 - - - F20 0
