FEATURE INFORMATION
6-31
RECORD 01h — 600h RECORD 15h — 790h
RECORD 02h — 614h RECORD 16h — 7A4h
RECORD 03h — 628h RECORD 17h — 7B8h
RECORD 04h — 63Ch RECORD 18h — 7CCh
RECORD 05h — 650h RECORD 19h — 7E0h
RECORD 06h — 664h RECORD 1Ah — 7F4h
RECORD 07h — 678h RECORD 1Bh — 808h
RECORD 08h — 68Ch RECORD 1Ch — 81Ch
RECORD 09h — 6A0h RECORD 1Dh — 830h
RECORD 0Ah — 6B4h RECORD 1Eh — 844h
RECORD 0Bh — 6C8h RECORD 1Fh — 858h
RECORD 0Ch — 6DCh RECORD 20h — 86Ch
RECORD 0Dh — 6F0h RECORD 21h — 880h
RECORD 0Eh — 704h RECORD 22h — 894h
RECORD 0Fh — 718h RECORD 23h — 8A8h
RECORD 10h — 72Ch RECORD 24h — 8BCh
RECORD 11h — 740h RECORD 25h — 8D0h
RECORD 12h — 754h RECORD 26h — 8E4h
RECORD 13h — 768h RECORD 27h — 8F8h
RECORD 14h — 77Ch RECORD 28h — 90Ch
Each of the event records is composed of 40 bytes as shown
below:
DATA BYTE DEFINITION FORMAT
0-2 Unused
3 Cause of event Refer to next table
4-7 Time of event Binary (-, Second, Minute, Hour)
8-11 Date of event Binary (-, Day, Month, Year)
12-15 Phase A Current
(If applicable)
Unsigned long integer
16-19 Phase B Current
(If applicable)
Unsigned long integer
20-23 Phase C Current
(If applicable)
Unsigned long integer
24-27 Ground Current
(If applicable)
Unsigned long integer
28-31 Voltage A
(Phase/Line, if applicable)
Unsigned long integer
32-35 Voltage B
(Phase/Line, if applicable)
Unsigned long integer
36-39 Voltage C
(Phase/Line, if applicable)
Unsigned long integer
The phase currents, ground current, and phase voltages are
of a double precision number format which is composed of 1
sign bit, 8 exponential bits, and 23 mantissa bits.
The following lists the possible events and the corresponding
hexadecimal number which will be found at byte 3 of each
event record. Only those events marked with an asterisk will
have their current and voltage parameters recorded.
EVENT NO DESCRIPTION APPLICABLE TO
01h (*) Phase A timed overcurrent trip 565/575
02h (*) Phase B timed overcurrent trip 565/575
03h (*) Phase C timed overcurrent trip 565/575
04h (*) Ground timed overcurrent trip 565/575
05h (*) Phase A inst. overcurrent trip 565
06h (*) Phase B inst. overcurrent trip 565
07h (*) Phase C inst. overcurrent trip 565
08h (*) Ground inst. overcurrent trip 565
09h (*) Phase A hiset instantaneous trip 575
0Ah (*) Phase B hiset instantaneous trip 575
0Bh (*) Phase C hiset instantaneous trip 575
0Ch (*) Ground hiset instantaneous trip 575
0Dh (*) Phase A loset instantaneous trip 575
0Eh (*) Phase B loset instantaneous trip 575
0Fh (*) Phase C loset instantaneous trip 575
10h (*) Ground loset instantaneous trip 575
11h (*) Overvoltage trip 565/575
12h (*) Undervoltage trip 565/575
13h Analog input trip 565/575
14h (*) External trip #1 565
15h (*) External trip #2 565
16h (*) External trip #3 565
17h (*) External trip #4 565
18h (*) External trip 575
19h (*) Reclosable trip 575
1Ah (*) Programmable trip 575
1Bh Power factor trip 565/575
1Ch Frequency trip 565/575
1Dh Voltage phase reversal trip 565/575
1Eh Phase overcurrent alarm 565/575
1Fh Ground overcurrent alarm 565/575
20h Overvoltage alarm 565/575
21h Undervoltage alarm 565/575
22h Analog input alarm 565/575
23h Accumulated KA alarm 565/575
24h Switch alarm #1 565/575
25h Switch alarm #2 565/575
26h Amps demand alarm 565/575
27h kW demand alarm 565/575
28h kvar demand alarm 565/575
29h Power factor alarm 565/575
2Ah Frequency alarm 565/575
2Bh Breaker discrepancy alarm 565/575
2Ch Trip coil alarm 565/575
2Dh MTM communication alarm 565/575
2Eh Phase overcurrent alarm reset 565/575
2Fh Ground overcurrent alarm reset 565/575
30h Overvoltage alarm reset 565/575
31h Undervoltage alarm reset 565/575
32h Analog input alarm reset 565/575
33h Switch alarm #1 reset 565/575
34h Switch alarm #2 reset 565/575
35h Breaker alarm reset 565/575
36h Access jumper installed 565/575
37h Access jumper removed 565/575
38h Block instantaneous trip enabled 565/575
39h Block instantaneous trip disabled 565/575
3Ah Block timed trips enabled 565/575
3Bh Block timed trips disabled 565/575
3Ch Curve adjust enabled 565/575
3Dh Curve adjust disabled 565/575
40h Illegal setpoint access 565/575
41h System manual reset 565/575
42h Reclosure enabled 575
43h Reclosure disabled 575
44h Control switch to remote 565/575
45h Control switch to local 565/575
46h Reclosure #1 575
47h Reclosure #2 575
EVENT NO DESCRIPTION APPLICABLE TO
