SPECIFICATIONS
9-2
Analog Output (Isolated):
Accuracy: ± 5% of full scale reading.
Range: 0 to 1 mA or 4 to 20 mA, software selectable.
Maximum Volts: maximum 30V (DC or p-pAC) can be present at
terminals.
Control Power:
AC voltage: 120 VAC and 240 VAC nominal. Range 90-260 VAC, 60
Hz.
DC voltage: 125 VDC and 250 VDC nominal. Range 95 to 280 VDC.
Maximum supply power:
50 Watts.
or
DC voltage: 48 VDC nominal. Range 20-60 VDC.
Maximum supply power:
25 Watts.
Environment:
565/575 Relay Display Only
Operating Temperature Range: -30°C to +80°C -20°C to +70°C
Storage Temperature: -30°C to +80°C -30°C to +80°C
NOTE: At extremely low temperatures (below -20°C), the 565/575 LCD
display exhibits very slow responses to alphanumeric changes.
At high temperatures (60°C and above) the LCD display darkens,
making it difficult to view displayed messages which indicate the
relay’s status.
Tests:
Dielectric strength: Hipot tested to:
Drawout case and terminal block: 2500 VAC, 50/60 Hz for 1 min.
Relay and drawout case: 1500 VAC, 50/60 Hz for 1 min.
Interference:
ANSI/IEEE: C37.90.1
Dimensions:
Overall depth behind mounting surface:
12.78"x7.75"x8.75"
Unit Weight: 20 lbs.
Shipping Weight:24 lbs.
Burn In Temperature:
60°C for 24 hours.
Design and specifications subject to change without notice.
