Location Message Line Description
*** Available only with Option Card installed **
A 9.1
ACTUAL VALUES
METERING DATA
The Actual Values page 9 header. This page allows the metering data to be
viewed.
Messages A 9.2 to A 9.6 will only appear if the Metering Transducer Module (MTM) has been enabled in setpoints.
A 9.2
POWER FACTOR
LAGGING 0.75
The Power Factor is displayed during this message.
A 9.3
FREQUENCY MTM
60.1 Hz
This message displays the frequency.
A 9.4
REAL POWER
65000 kW
This message displays the current real power delivered. If communicating
with a rev. E MTM or MTM Plus, the kW polarity sign will be included.
A 9.5
REACTIVE POWER
65000 kVAR
This message displays the current reactive power. If communicating with a
rev. E MTM or MTM Plus, the kW polarity sign will be included.
A 9.6
ENERGY USED
65000 MWHRS
This message displays the real power used.
A 9.7
CLEAR ENERGY
USED DATA? NO
This prompts the user if Energy Used Data is to be cleared. If YES, data
stored will be erased. The MWhrs should be cleared after 65,000 in order
to ensure safe operation.
MWh data on MTM can be cleared now by using 565/575 Relay's keypad
or Modbus communication command.
A 9.7
METERING DATA
END OF PAGE
The last line of METERING DATA page. This is the last page of ACTUAL
VALUES.
ACTUAL VALUES MODE - METERING DATA
