Location Message Line Description
The following are messages specific to the 565; messages specific to the 575 will be indicated as required.
S 4.16
EXTERNAL TRIP #1
DELAY 0 CYC
This message asks for any time delay needed on the operation of the
switch. This means that if one of the internal relays is to be energized by
this switch it will only be energized if the switch is activated for the assigned
time. The range for this setpoint is 0 (Inst.) to 60 cycles, in steps of 1 cycle.
S 4.17
EXTERNAL TRIP #2
DISABLED
If this function is assigned to a switch then it will cause the input to act as
an external trip for the feeder breaker.
Message S 4.18 and S 4.19 will appear only if the External Trip function in message S 4.17 is assigned to a switch.
S 4.18
EXTERNAL TRIP #2
RELAY TRIP&AUX1
Enter which output relay will activate when the above trip occurs.
S 4.19
EXTERNAL TRIP #2
DELAY 0 CYC
This message asks for any time delay needed on the operation of the
switch. This means that if one of the internal relays is to be energized by
this switch it will only be energized if the switch is activated for the assigned
time. The range for this setpoint is 0 (Inst.) to 60 cycles, in steps of 1 cycle.
S 4.20
EXTERNAL TRIP #3
DISABLED
If this function is assigned to a switch then it will cause the input to act as
an external trip for the feeder breaker.
Message S 4.21 and S 4.22 will appear only if the External Trip function in message S 4.20 is assigned to a switch.
S 4.21
EXTERNAL TRIP #3
RELAY TRIP&AUX1
Enter which output relay will activate when the above trip occurs.
S 4.22
EXTERNAL TRIP #3
DELAY 0 CYC
This message asks for any time delay needed on the operation of the
switch. This means that if one of the internal relays is to be energized by
this switch it will only be energized if the switch is activated for the assigned
time. The range for this setpoint is 0 (Inst.) to 60 cycles, in steps of 1 cycle.
S 4.23
EXTERNAL TRIP #4
DISABLED
If this function is assigned to a switch then it will cause the input to act as
an external trip for the feeder breaker.
Messages S 4.24 and S 4.25 will appear only if the External Trip function in message S 4.23 is assigned to a switch.
S 4.24
EXTERNAL TRIP #4
RELAY TRIP&AUX1
Enter which output relay will activate when the above trip occurs.
S 4.25
EXTERNAL TRIP #4
DELAY 0 CYC
This message asks for any time delay needed on the operation of the
switch. This means that if one of the internal relays is to be energized by
this switch it will only be energized if the switch is activated for the assigned
time. The range for this setpoint is 0 (Inst.) to 60 cycles, in steps of 1 cycle.
S 4.26
CURVE ADJUSTMENT
DISABLED
If an external switch is assigned this function then the timed overcurrent
curve in use will not start to time out until the current is above pickup by
10%. Essentially, the bottom part of the curve that falls between 100 and
110% disappears, yet the time to trip above this level would remain the
same.
L
A
L
A
L
A
L
A
L
A
L
A
L
A
L
A
L
A
L
A
L
A
SETPOINTS MODE - CONFIGURATION
To Next Page
