5-28
Location Message Line Description
CONDITION
OUTPUT
AUX. 1 RELAY
FACEPLATE
AUX. 1 LED
MODBUS READ EXCEPTION
STATUS
NO ALARM DE-ENERGIZED OFF 00H
ALARM
(Alarm Level < Curr. < P/U)
(Brkr. Open)
PULSES ON 40H
ALARM
(Curr. > Alarm & P/U Level)
ENERGIZED OFF 40H
ALARM
(Curr. < Alarm & P/U Level)
(Brkr. Open)
DE-ENERGIZED OFF 00H
KEYPAD RESET DE-ENERGIZED OFF 00H
Latched
If latched operation is chosen for the Aux 1 relay, it will energize when a
trip/alarm occurs. Pressing the RESET key on the front panel will unlatch
the Aux 1 relay only if the fault current is below the trip/alarm level. This
may be convenient if the relay is being used to annunciate a fault condition.
When programmed as latched, the Aux 1 relay does not look at the 52a/
52b contacts.
CONDITION
OUTPUT AUX. 1
RELAY
FACEPLATE
AUX. 1 LED
MODBUS READ EXCEPTION
STATUS
NO TRIP DE-ENERGIZED OFF 00H
TRIPPED
(Current > Trip Level)
ENERGIZED ON 44H
TRIPPED
(Current < Trip Level)
ENERGIZED ON 44H
KEYPAD RESET DE-ENERGIZED OFF 00H
CONDITION
OUTPUT AUX. 1
RELAY
FACEPLATE
AUX. 1 LED
MODBUS READ EXCEPTION
STATUS
NO ALARM DE-ENERGIZED OFF 00H
ALARM
(Current > Alarm Level)
ENERGIZED ON 40H
ALARM
(Current < Alarm Level)
ENERGIZED ON 40H
KEYPAD RESET DE-ENERGIZED OFF 00H
Unlatched
If unlatched operation is selected, the Aux 1 relay becomes energized
upon declaration of a fault/ alarm condition. When current drops below the
alarm/trip level, the relay will de-energize. When programmed as un-
latched, the Aux 1 relay does not look at the 52a/52b contacts.
SETPOINTS MODE - CONFIGURATION
