Location Message Line Description
S 7.1
SETPOINTS
COMMUNICATIONS
The setpoints page 7 header. This page contains setpoints which affect
how the 565 Relay communicates with other devices.
S 7.2
RELAY ADDRESS
1
This message is used to assign each relay a different address or number
to distinguish it from all other relays being used in a serial communication
link. The range of values which may be entered is 1 to 254 in steps of 1.
S 7.3
BAUDRATE
2400 BAUD
This setpoint is used to select the data transfer rate for serial communica-
tions via the front Programming Port or the rear Communication Port. Use
NEXT CHOICE key to select either 1200, 2400, 4800, or 9600 BAUD.
S 7.4
COMMUNICATIONS
END OF PAGE
The last line of page 7, setpoints. Press the PAGE key to view page 7.
SETPOINTS MODE - COMMUNICATION
