5-45
Location Message Line Description
Messages S 10.10 and S 10.11 will only appear if the Demand KW Alarm feature is enabled in message S 10.9.
S 10.10
KW DEMAND ALARM
LEVEL 1000 kW
The kW Demand alarm level is specified here. The range is 100 to 65000
kW in steps of 100 kW.
S 10.11
KW DEMAND ALARM
RELAY AUX1
This message allows the user to select the relay which will be activated
when an alarm occurs.
S 10.12
KVAR DEMAND
ENABLED
This message allows the user to enable or disable the kVAR demand
feature. If this feature is disabled the Peak kVAR Demand value will be the
last peak value before the feature was disabled.
Messages S 10.13 to S 10.16 will only appear if ENABLED is selected in message S 10.12.
S 10.13
KVAR DEMAND TIME
PERIOD 5 MIN
This message allows the user to specify the time period over which the
kVAR demand is calculated. The range of values is 5 to 120 minutes in
steps of 1 minute. NOTE: If this setpoint or the Phase CT Primary rating
are changed the kVAR demand function will be reset and the peak kVAR
Demand value shown in the Metering Data will be cleared.
S 10.14
KVAR DEMAND
ALARM DISABLED
This message allows the user to enable or disable the alarm function.
Messages S 10.15 and S 10.16 will only appear if the Demand kVAR Alarm feature is enabled in message S 10.14.
S 10.15
KVAR DEMAND AL'M
LEVEL 1000 kVAR
The kVAR Demand alarm level is specified here. The range is 100 to 65000
kW in steps of 100 kW.
S 10.16
KVAR DEMAND AL'M
RELAY AUX1
The user is allowed to select the relay which will be activated when an
alarm occurs.
S 10.17
DEMAND METERING
END OF PAGE
End of page 10, setpoints. Press the PAGE key to view page 11.
SETPOINTS MODE - DEMAND METERING
