5-47
Location Message Line Description
S 11.11
POWER FACTOR
TRIP DISABLED
This message allows the user to enable or disable the trip feature for the
Power Factor.
Messages S 11.12 to S 11.15 appear only if the Power Factor Trip feature has been enabled in message S 11.11.
S 11.12
P/F LEADING TRIP
LEVEL 0.70
The leading trip level is chosen here. The range is 0 to 1 in steps of 0.05.
S 11.13
P/F LAGGING TRIP
LEVEL 0.70
The lagging trip level is chosen here. The range is 1 to 0 in steps of 0.05.
S 11.14
P/F TRIP DELAY
1.0 SEC
The delay time before a trip is given can be selected here. Range is 1 - 127
sec. in steps of 0.5 sec.
S 11.15
P/F TRIP RELAY
AUX1
This message indicates which relay will be activated when the trip level is
exceeded.
S 11.16
FREQUENCY ALARM
DISABLED
This message allows the user to enable or disable the frequency alarm
feature.
Messages S 11.17 to S 11.20 appear only if the Frequency Alarm feature has been enabled in message S 11.16.
S 11.17
UNDER FREQ ALARM
LEVEL 58.0 Hz
The under frequency alarm level is chosen here. The range is 40 - 60 Hz
in steps of 0.1.
S 11.18
OVER FREQ ALARM
LEVEL 62.0 Hz
The over frequency alarm level is chosen here. The range is 50 - 72 Hz in
steps of 0.1.
S 11.19
FREQUENCY ALARM
DELAY 5.0 SEC
The delay time before an alarm is given can be selected here. Range is 1
- 127 sec. in steps of 0.5 sec.
S 11.20
FREQUENCY ALARM
RELAY AUX1
This message indicates which relay will be activated when the alarm level
is exceeded.
S 11.21
FREQUENCY TRIP
DISABLED
This message allows the user to enable or disable the frequency trip
feature.
Messages S 11.22 to S 11.25 appear only if the Frequency Trip feature has been enabled in message S 11.21.
S 11.22
UNDER FREQ. TRIP
LEVEL 56.0 Hz
The under frequency trip level is chosen here. The range is 40 - 60 Hz in
steps of 0.1.
S 11.23
OVER FREQ. TRIP
LEVEL 64.0 Hz
The over frequency trip level is chosen here. The range is 50 - 72 Hz in
steps of 0.1.
SETPOINTS MODE - MTM METERING
