Location Message Line Description
S 14.1
SETPOINTS
GROUND CURVES
The setpoints page 14 header. Setpoints required to program an alternate
ground curve are entered here.
S 14.2
GROUND CURVE
CHANGE DISABLED
This will enable the changing of the ground curve.
Only message S 14.8 will appear if DISABLED is selected in message S 14.2.
S 14.3
SWITCH TO CURVE2
AFTER RECL. # 1
Enter which reclosure you wish to close onto using the alternative ground
curve. Alternative curves will remain until lockout occurs.
S 14.4
GND O/C CURVE 2
SHAPE EXTREM INV
Enter the curve shape for the alternative ground curve.
Message S 14.5 will not appear if CUSTOM2 was selected in message S 14.4.
S 14.5
GROUND O/C TIME
DIAL 2 1
Enter the time dial for the alternative ground curve.
Messages S14.6 and S14.7 will only appear if CUSTOM2 was selected in message S14.4.
S 14.6
TRIP TIME2 (SEC)
1.03 xP/U= 1.0
The trip time for the first breakpoint of the programmable alternative
ground curve is entered here. The breakpoints are multiples of the pickup
current.
The remainder of the messages in this section are identical to those found in the GROUND CURRENT page of setpoints.
S 14.7
TRIP TIME2 (SEC)
20.0 xP/U= 1.0
The last trip time is entered here.
S 14.8
GROUND CURVES
END OF PAGE
Last line of Setpoints, page 14. This is the last page of Setpoints.
