138 MM300 MOTOR MANAGEMENT SYSTEM – COMMUNICATIONS GUIDE
FIELDBUS INTERFACE CHAPTER 1: COMMUNICATIONS GUIDE
DeviceNet - Explicit
Motor Object, Class
Code B1H
Table 39: Explicit Motor Control Object, Class Code B1h, Services:
Table 40: Explicit Motor Control Object, Class Code B1h, Attributes:
Table 41: Explicit Motor Control Data Format
15H Last pre-trip power Pre Trip Real Power 4 F13
Pre Trip Reactive Power 4 F13
Pre Trip Apparent Power 2 F2
Pre Trip Power Factor 2 F21
16H Trip diagnostic data Trip Status 3 4 FC185
Trip Status 2 4 FC184
Trip Status 1 4 FC183
17H Alarm diagnostic data Alarm Status 3 4 FC181
Alarm Status 2 4 FC180
Alarm Status 1 4 FC179
18H Start block status data Reserved 2 F1
Start Timer 1 2 F1
Start Timer 2 2 F1
Start Timer 3 2 F1
Start Timer 4 2 F1
Start Timer 5 2 F1
Time Between Starts Lockout 2 F1B
Restart Block Lockout 2 F1
Starts/Hour Block 2 F1
19H All of the above items from attributes 01H-18H
ATTRIBUTE ITEM DESCRIPTION SIZE IN
BYTES
FORMAT
CODE SERVICES AVAILABLE TO THIS OBJECT
NAME DESCRIPTION
0x10 Set_Attribute_Single Sets the contents of the given attribute
ATTRIBUTE ACCESS DESCRIPTION DATA TYPE VALUE
01H Set Control Command BYTE See below
VALUE DESCRIPTION
Dec Hex
1 0x01 Reset
20x02Lockout Reset
30x03Stop
40x04Start A
50x05Start B
66 0x42 Clear Last Trip Data Prompt
67 0x43 Reset MWh and Mvarh Meters
68 0x44 Clear Counters
69 0x45 Clear Event Records
70 0x46 Clear Waveform Data
71 0x47 Clear Maintenance Timer
72 0x48 Clear RTD Maximums
73 0x49 Reset Motor Information
74 0x4A Auto Mode
