78 MM300 MOTOR MANAGEMENT SYSTEM – COMMUNICATIONS GUIDE
FIELDBUS INTERFACE CHAPTER 1: COMMUNICATIONS GUIDE
Profibus Output Data The capability to reset, stop, and start the motor has been made available via the Profibus
Output data. Because polled output data is continuously written to the slave device, the
MM300 looks for a change in the value to execute any command.
Profibus DPV0-
Diagnostics
The MM300 supports both slave mandatory (6 bytes system-wide standardized) and slave
specific extended diagnostic data. If the diagnostics are considered high priority, the PLC/
host program will be informed of the fault (alarm, trip, command, or message) and can call
a special error routine. When no extended diagnostic information is available and the
master initiates a diagnostics read, only the six standard slave mandatory bytes are read,
formatted as follows:
Table 12: System Standard Diagnostics Bytes 1 through 6
Byte Value Description
Dec Hex
0 0 0x00 Reserved Byte
110x01Reset
20x02Lockout Reset
40x04Stop
80x08Start A
16 0x10 Start B
66 0x42 Clear Last Trip Data Prompt
67 0x43 Reset MWh and Mvarh Meters
68 0x44 Clear Counters
69 0x45 Clear Event Records
70 0x46 Clear Waveform Data
71 0x47 Clear Maintenance Timer
72 0x48 Clear RTD Maximums
73 0x49 Reset Motor Information
74 0x4A Auto Mode
75 0x4B Manual Mode
76 0x4C Manual Inhibit
77 0x4D Manual Restore
78 0x4E Start Inhibit
79 0x4F Start Restore
80 0x50 Trigger Waveform Capture
81 0x51 Start Datalog
82 0x52 Stop Datalog
Byte Description Measured Value
1 Station Status 1 0x08
2 Station Status 2 0x0C
3 Station Status 3 0x00
4 Diagnostic Master Address 0x7D
5 Identification Number (High Byte) 0x0C
6 Identification Number (Low Byte) 0x52
