92 MM300 MOTOR MANAGEMENT SYSTEM – COMMUNICATIONS GUIDE
FIELDBUS INTERFACE CHAPTER 1: COMMUNICATIONS GUIDE
Table 15: DPV1 acyclic write data
Profibus DPV1-
Diagnostics
MM300 DPV1 diagnosis data is structured as shown below:
The extended diagnosis consists of Process Alarms and Diagnostic Alarms.
Trip, Alarm, and Control status are categorized as Process Alarms, as these provide
information pertaining to the Motor health that MM300 is controlling and monitoring.
Messages are categorized as Diagnostic Alarms as these provide detailed MM300
diagnostic information.
The detailed message layout explaining what information each bit provides is as follows:
Object Slot Index Value Description
Dec Hex
0001 0x01 Reset
0002 0x02 Lockout Reset
0004 0x04 Stop
0008 0x08 Start A
00016 0x10 Start B
00066 0x42 Clear Last Trip Data Prompt
00067 0x43 Reset MWh and Mvarh Meters
00068 0x44 Clear Counters
00069 0x45 Clear Event Records
00070 0x46 Clear Waveform Data
00071 0x47 Clear Maintenance Timer
00072 0x48 Clear RTD Maximums
00073 0x49 Reset Motor Information
00074 0x4A Auto Mode
00075 0x4B Manual Mode
00076 0x4C Manual Inhibit
00077 0x4D Manual Restore
00078 0x4E Start Inhibit
00079 0x4F Start Restore
00080 0x50 Trigger Waveform Capture
00081 0x51 Start Datalog
00082 0x52 Stop Datalog
To Next Page
