40 MM300 MOTOR MANAGEMENT SYSTEM – COMMUNICATIONS GUIDE
RS485 INTERFACE (MODBUS RTU) CHAPTER 1: COMMUNICATIONS GUIDE
41554 0611 UVR Short Dip Time 100 510 10 ms F1
*
200 1
41555 0612 UVR Med Dip Time 1 100 1 s F2 20 1
41556 0613 UVR Long Dip Time 5 605 5 min F2
*
605 1
41557 0614 UVR Med Dip Delay 2 600 2 s F2 20 1
41558 0615 UVR Long Dip Delay 10 12000 10 s F2 100 1
41559 0616 UVR Dropout Level 60 100 1 % F1 65 1
41560 0617 UVR Pickup Level 60 100 1 % F1 90 1
41561 0618 Reserved --- --- --- --- --- --- 1
▼▼▼ ▼ ▼ ▼▼▼▼ ▼
41570 0621 Reserved --- --- --- --- --- --- 1
AUTO / MANUAL CONTROL
41571 0622 Comm Stop Action 0 1 1 FC174 0 1
41572 0623 Comms Start Ctrl 0 1 1 --- FC126 0 1
41573 0624 Comms Stop Mode 0 1 1 --- FC172 0 1
41574 0625 Hard Wired Start Ctrl 0 1 1 --- FC126 0 1
41575 0626 Hard Wired Stop Mode 0 1 1 --- FC172 0 1
41576 0627 Hard Wired Stop Actn 0 1 1 --- FC174 0 1
41577 0628 Hard Wired 2W/3W 0 1 1 --- FC173 1 1
41578 0629 Field Start Ctrl 0 1 1 --- FC126 0 1
41579 062A Field Stop Mode 0 1 1 --- FC172 0 1
41580 062B Field Stop Action 0 1 1 --- FC174 0 1
41581 062C Field 2W/3W 0 1 1 --- FC173 1 1
41582 062D MCC Start Ctrl 0 1 1 --- FC126 0 1
41583 062E MCC Stop Mode 0 1 1 --- FC172 0 1
41584 062F MCC Stop Action 0 1 1 --- FC174 0 1
41585 0630 Test Auto Mode 0 2 1 --- FC175 1 1
41586 0631 Test Manual Mode 0 2 1 --- FC175 0 1
41587 0632 External Stop Action 0 1 1 --- FC174 0 1
41588 0633 Auto/Manual Key 0 1 1 --- FC126 0 1
41589 0634 Reserved --- --- --- --- --- --- 7
▼▼▼ ▼ ▼ ▼▼▼▼ ▼
41696 069F Reserved 1
FLEXLOGIC EQUATION
41697 06A0 Flex Equation 0 0xFFFF 1 FC142 0x400 512
42209 08A0 Reserved --- --- --- --- --- --- 1
▼▼▼ ▼ ▼ ▼▼▼▼ ▼
43763 0EB2 Reserved 2
1.Maximum setpoint value represents OFF
Modbus Hex Description Min Max Step Units Format Default Size in
Words
