CHAPTER 1: COMMUNICATIONS GUIDE RS485 INTERFACE (MODBUS RTU)
MM300 MOTOR MANAGEMENT SYSTEM – COMMUNICATIONS GUIDE 43
F25 16 bits TRACE MEMORY CHANNEL DATA
0Leading
1 Lagging
F26 16 bits TRACE MEMORY CHANNEL DATA
0Va
1Vb
2Vc
3Va2
4Vb2
5Vc2
6Ia
7Ib
8Ic
9Ig
10 Inputs 1 to 16
11 Outputs 1 to 16
F74 16 bits DATA LOGGER SAMPLE RATE
0 1 cycle
11 second
21 minute
3 1 hour
F75 16 bits TRACE MEMORY CHANNEL DATA
0Stopped
1Started
2 Triggered
3 Pretrigger
4 PostTrigger
F77 16 bits DATA LOGGER CHANNEL DATA
0 Disabled
1 Phase A Current
2Phase B Current
3Phase C Current
4 Average Phase Current
5Motor Load
6 Current Unbalance
7 Ground Current
8 System Frequency
9Vab
10 Vbc
11 Vca
12 Van
13 Vbn
14 Vcn
15 Power Factor
16 Real Power (kW)
17 Reactive Power (kvar)
18 Apparent Power (kVA)
Code Type Definition
