CHAPTER 1: COMMUNICATIONS GUIDE RS485 INTERFACE (MODBUS RTU)
MM300 MOTOR MANAGEMENT SYSTEM – COMMUNICATIONS GUIDE 45
FC111 16 bits Trip Relays
0Trip
1Alarm
FC112 16 bits Communication Status
0Error
1OK
FC116 16 bits Switch Type
0Open
1Closed
FC121 16 bits RTD Application
0None
1Stator
2Bearing
3Ambient
4Other
FC122 16 bits RTD Voting Selection
0OFF
1RTD #1
2RTD #2
3RTD #3
4RTD #4
5RTD #5
6RTD #6
FC126 16 bits Disabled / Enabled Selection
0 Disabled
1 Enabled
FC128 16 bits Command Status
0 Manual
1Auto
2 Manual Inhibit
3 Auto/ Manual
4 Hardwired Auto
5None
FC129 16 bits Quick Status
Bit 0 Alarm
Bit 1 Trip
Bit 2 Self Test Fault
Bit 3 Auto
Bit 4 Contactor A
Bit 5 Contactor B
Bit 6 Contact Output 3
Bit 7 Drive Available
FC130 16 bits LED Flash
Bit 0 Running
Bit 1 Stopped
Bit 2 Tripped
Bit 3 Alarm
Code Type Definition
To Next Page
