66 MM300 MOTOR MANAGEMENT SYSTEM – COMMUNICATIONS GUIDE
RS485 INTERFACE (MODBUS RTU) CHAPTER 1: COMMUNICATIONS GUIDE
Bit 4 AutoManualMode
Bit 5 Restart Inhibit
Bit 6 Contactor A
Bit 7 Contactor B
Bit 8 Forward Limit
Bit 9 Reverse Limit
Bit 10 Starts/Hr Inhibit
Bit 11 Time Between Inhibit
Bit 12 Level 1 Access
Bit 13 Level 2 Access
Bit 14 Level 3 Access
Bit 15 Comms Ctrl Active
Bit 16 Hard Wired Ctrl Active
Bit 17 Field Ctrl Active
Bit 18 MCC Ctrl Active
Bit 19 Process ILock A Stop
Bit 20 Process ILock B Stop
Bit 21 Process ILock C Stop
Bit 22 Process ILock D Stop
Bit 23 Process ILock E Stop
Bit 24 Process ILock F Stop
Bit 25 Process ILock G Stop
Bit 26 Process ILock H Stop
Bit 27 Process ILock I Stop
Bit 28 Process ILock J Stop
Bit 29 HW Stop
Bit 30 Field Stop
Bit 31 MCC Stop
FC192 32 bits Ctrl Element Status 2
Bit 0 Access Switch
Bit 1 Test Switch
Bit 2 Hard Wired Start A
Bit 3 Hard Wired Start B
Bit 4 Start A
Bit 5 Start B
Bit 6 Field Start A
Bit 7 Field Start B
Bit 8 Contactor A Status
Bit 9 Contactor B Status
Bit 10 Remote Reset
Bit 11 Lockout Reset
Bit 12 UV Restart
Bit 13 Pre-Contactor
Bit 14 MCC Start A
Bit 15 MCC Start B
Bit 16 Bypass Contact
Bit 17 Comm Start A
Code Type Definition
