CHAPTER 1: COMMUNICATIONS GUIDE FIELDBUS INTERFACE
MM300 MOTOR MANAGEMENT SYSTEM – COMMUNICATIONS GUIDE 81
58 17 2 82 "Fuse Fail Trip" 11
59 17 3 83 "OpenControl Circuit" 11
60 17 4 84 "Thermistor Trip" 11
61 17 5 85 11
62 17 6 86 11
63 17 7 87 "Self Test Trip" 11
64 18 0 88 "Process ILock F Trip" 12
65 18 1 89 "Process ILock G Trip" 12
66 18 2 90 "Process ILock H Trip" 12
67 18 3 91 "Process ILock I Trip" 12
68 18 4 92 "Process ILock J Trip" 12
69 18 5 93 "Hard Wired Trip" 12
70 18 6 94 "Field Trip" 12
71 18 7 95 "MCC Trip" 12
72 19 0 96 "RTD 6 Trip" 13
73 19 1 97 "Comm Fail Trip" 13
74 19 2 98 "Relay Not Configured" 13
75 19 3 99 "Process ILock A Trip" 13
76 19 4 100 "Process ILock B Trip" 13
77 19 5 101 "Process ILock C Trip" 13
78 19 6 102 "Process ILock D Trip" 13
79 19 7 103 "Process ILock E Trip" 13
80 20 0 104 "Mechanical Jam Trip" 14
81 20 1 105 "UnderCurrent Trip" 14
82 20 2 106 "Unbalance Trip" 14
83 20 3 107 "RTD 1 Trip" 14
84 20 4 108 "RTD 2 Trip" 14
85 20 5 109 "RTD 3 Trip" 14
86 20 6 110 "RTD 4 Trip" 14
87 20 7 111 "RTD 5 Trip" 14
88 21 0 112 "Any Trip" 15
89 21 1 113 "Thermal O/L Trip" 15
90 21 2 114 "Ground Fault Trip" 15
91 21 3 115 "Acceleration Trip" 15
92 21 4 116 "Phase Reversal Trip" 15
93 21 5 117 "UnderPower Trip" 15
94 21 6 118 "UnderVoltage Trip" 15
95 21 7 119 "OverVoltage Trip" 15
96 22 0 120 Reserved 16
97 22 1 121 Reserved 16
98 22 2 122 Reserved 16
99 22 3 123 Reserved 16
100 22 4 124 Reserved 16
101 22 5 125 Reserved 16
102 22 6 126 Reserved 16
Byte Bit GSE Bit # Ext.
Diag
Byte
To Next Page
