CHAPTER 1: COMMUNICATIONS GUIDE FIELDBUS INTERFACE
MM300 MOTOR MANAGEMENT SYSTEM – COMMUNICATIONS GUIDE 83
148 28 4 172 "Load Increase Alarm" 22
149 28 5 173 "Drive Greasing Alarm" 22
150 28 6 174 "Contactor Inspect Alarm" 22
151 28 7 175 "Max Stopped Alarm" 22
152 29 0 176 "Aux U/V Alarm" 23
153 29 1 177 "External Stop Alarm" 23
154 29 2 178 "Fuse Fail Alarm" 23
155 29 3 179 "Open Ctrl Cct Alarm" 23
156 29 4 180 "Thermistor Alarm" 23
157 29 5 181 Reserved 23
158 29 6 182 "External Start A Alarm" 23
159 29 7 183 "External Start B Alarm" 23
160 30 0 184 "Process ILock F Alarm" 24
161 30 1 185 "Process ILock G Alarm" 24
162 30 2 186 "Process ILock H Alarm" 24
163 30 3 187 "Process ILock I Alarm" 24
164 30 4 188 "Process ILock J Alarm" 24
165 30 5 189 "Drive Failed to Start" 24
166 30 6 190 "Inverter Failed" 24
167 30 7 191 "Drive Stop Failed" 24
168 31 0 192 "RTD 6 Alarm" 25
169 31 1 193 Reserved 25
170 31 2 194 "RTD Open/Short Alarm" 25
171 31 3 195 "Process ILock A Alarm" 25
172 31 4 196 "Process ILock B Alarm" 25
173 31 5 197 "Process ILock C Alarm" 25
174 31 6 198 "Process ILock D Alarm" 25
175 31 7 199 "Process ILock E Alarm" 25
176 32 0 200 Reserved 26
177 32 1 201 "UnderCurrent Alarm" 26
178 32 2 202 "Unbalance Alarm" 26
179 32 3 203 "RTD 1 Alarm" 26
180 32 4 204 "RTD 2 Alarm" 26
181 32 5 205 "RTD 3 Alarm" 26
182 32 6 206 "RTD 4 Alarm" 26
183 32 7 207 "RTD 5 Alarm" 26
184 33 0 208 "Any Alarm" 27
185 33 1 209 "Thermal Level Alarm" 27
186 33 2 210 "Ground Fault Alarm" 27
187 33 3 211 "Acceleration Alarm" 27
188 33 4 212 "Phase Reversal Alarm" 27
189 33 5 213 "UnderPower Alarm" 27
190 33 6 214 "UnderVoltage Alarm" 27
191 33 7 215 "OverVoltage Alarm" 27
192 34 0 216 Reserved 28
Byte Bit GSE Bit # Ext.
Diag
Byte
To Next Page
