CHAPTER 1: COMMUNICATIONS GUIDE FIELDBUS INTERFACE
MM300 MOTOR MANAGEMENT SYSTEM – COMMUNICATIONS GUIDE 85
238 39 6 262 "Low Aux Voltage Inhibit" 33
239 39 7 263 "UV Restart Inhibit" 33
240 40 0 264 Reserved 34
241 40 1 265 Reserved 34
242 40 2 266 Reserved 34
243 40 3 267 Reserved 34
244 40 4 268 "UV Restart" 34
245 40 5 269 Reserved 34
246 40 6 270 Reserved 34
247 40 7 271 Reserved 34
248 41 0 272 Reserved 35
249 41 1 273 Reserved 35
250 41 2 274 Reserved 35
251 41 3 275 Reserved 35
252 41 4 276 Reserved 35
253 41 5 277 Reserved 35
254 41 6 278 Reserved 35
255 41 7 279 Reserved 35
256 42 0 280 "Process ILock F Stop" 36
257 42 1 281 "Process ILock G Stop" 36
258 42 2 282 "Process ILock H Stop" 36
259 42 3 283 "Process ILock I Stop" 36
260 42 4 284 "Process ILock J Stop" 36
261 42 5 285 "HW Stop" 36
262 42 6 286 "Field Stop" 36
263 42 7 287 "MCC Stop" 36
264 43 0 288 Reserved 37
265 43 1 289 Reserved 37
266 43 2 290 Reserved 37
267 43 3 291 "Process ILock A Stop" 37
268 43 4 292 "Process ILock B Stop" 37
269 43 5 293 "Process ILock C Stop" 37
270 43 6 294 "Process ILock D Stop" 37
271 43 7 295 "Process ILock E Stop" 37
272 44 0 296 "Forward Limit" 38
273 44 1 297 "Reverse Limit" 38
274 44 2 298 "Starts/Hr Inhibit" 38
275 44 3 299 "Time Between Inhibit" 38
276 44 4 300 Reserved 38
277 44 5 301 Reserved 38
278 44 6 302 Reserved 38
279 44 7 303 Reserved 38
280 45 0 304 "Any Stop" 39
281 45 1 305 "Thermal Inhibit" 39
282 45 2 306 Reserved 39
Byte Bit GSE Bit # Ext.
Diag
Byte
To Next Page
