CHAPTER 1: COMMUNICATIONS GUIDE FIELDBUS INTERFACE
MM300 MOTOR MANAGEMENT SYSTEM – COMMUNICATIONS GUIDE 95
29 13 5 53 Reserved 7
30 13 6 54 Reserved 7
31 13 7 55 Reserved 7
32 14 0 56 Reserved 8
33 14 1 57 Reserved 8
34 14 2 58 Reserved 8
35 14 3 59 Reserved 8
36 14 4 60 Reserved 8
37 14 5 61 Reserved 8
38 14 6 62 Reserved 8
39 14 7 63 Reserved 8
40 15 0 64 Reserved 9
41 15 1 65 Reserved 9
42 15 2 66 Reserved 9
43 15 3 67 Reserved 9
44 15 4 68 Reserved 9
45 15 5 69 Reserved 9
46 15 6 70 Reserved 9
47 15 7 71 Reserved 9
48 16 0 72 Reserved 10
49 16 1 73 Reserved 10
50 16 2 74 Reserved 10
51 16 3 75 Reserved 10
52 16 4 76 Reserved 10
53 16 5 77 Reserved 10
54 16 6 78 Reserved 10
55 16 7 79 Reserved 10
56 17 0 80 "Aux U/V Trip" 11
57 17 1 81 "Emergency Stop" 11
58 17 2 82 "Fuse Fail Trip" 11
59 17 3 83 "OpenControl Circuit" 11
60 17 4 84 "Thermistor Trip" 11
61 17 5 85 11
62 17 6 86 11
63 17 7 87 "Self Test Trip" 11
64 18 0 88 "Process ILock F Trip" 12
65 18 1 89 "Process ILock G Trip" 12
66 18 2 90 "Process ILock H Trip" 12
67 18 3 91 "Process ILock I Trip" 12
68 18 4 92 "Process ILock J Trip" 12
69 18 5 93 "Hard Wired Trip" 12
70 18 6 94 "Field Trip" 12
71 18 7 95 "MCC Trip" 12
72 19 0 96 "RTD 6 Trip" 13
73 19 1 97 "Comm Fail Trip" 13
Byte Bit GSE Bit # Ext.
Diag
Byte
To Next Page
