Page #28 background image
28
NX-8V2 Control
LOCATIONS 110-169 ARE USED TO CHANGE THE ZONE TYPES (Configurations) AS LISTED IN THE TABLE ON PAGE 16.
THESE LOCATIONS ARE CONSIDERED ADVANCED PROGRAMMING AND SHOULD ONLY BE CHANGED WITH A THOROUGH
UNDERSTANDING OF THE OPERATION OF EACH BIT.
110 ZONE TYPE 1 ALARM EVENT CODE 1 ............ numerical
Location 110 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 16. The zone ID will be that zone that is in alarm.
4+2 Format Note
: If 4+2 format is being used, the number programmed in this location will be sent as the upper hex digit. The digit in
location 110 should be from 1 to 15 when using 4+2 formats. The zone ID or user ID will be the lower hex digit of the zone that is in
alarm.
111 ZONE TYPE 1 CHARACTERISTIC SELECT 5 ............ feature select
Segment 1:
1 = Fire (turn on if this is a fire zone).
2 = 24 hour (turn on for non-fire 24 hour zones).
3 = Keyswitch zone. (normally open switch)
4 = Follower (turn on for burglary zones that are Instant during non-entry times).
5 = Delay 1 zone (follows timer 1 entry and exit times).
6 = Delay 2 zone (follows timer 2 entry and exit times).
7 = Interior (turn on if this zone should Automatically Bypass or Bypass for Stay Arming).
8 = Local only (turn on if this zone should not be reported).
Segment 2:
1 = On if Zone Type will beep the keypad for alarm.
2 = On if Zone Type will sound the yelping siren for alarm.
3 = On if Zone Type will sound the temporal siren for alarm.
4 = On if Zone Type will chime.
5 = On if Zone Type can be bypassed.
6 = On if Zone Type is included in the group shunt.
7 = On if Zone Type is force armable.
8 = On if Zone Type is entry guard.
Segment 3:
1- On enables Fast Loop Response. (50mS)- Off= 500mS
2- On enables Double End Of Line Tamper zone. (Mainly used for tamper on wireless zones)
3- On enables Trouble Reporting zone. (Day zone and Fire zones)
4- On if Zone Type is a Cross Zone.
5- On enables Dialer Delay zone. (See location 40, page 20)
6- On if Zone Type will swinger shutdown. (See location 38, page 20)
7- On enables Restore reporting.
8- On enables Listen-In. (See location 40, page 20)
Segment 4:
1 = On enables Zone Activity Monitor. (See location 40, page 20)
2 = On enables End of Line Resistor Defeat on Non-Fire/Non-Keyswitch zones.
3 = On enables zone to act as request to exit input / disables for alarm activation.
4 = On enables zone to act as access entry point (Refer to NX-1700E card reader instruction manual. Do not enable this segment
unless configured with Access Control.)
5-8 = Reserved.
Segment 5: Reserved.
112 ZONE TYPE 2 ALARM EVENT CODE 1 ............ numerical
Location 112 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details.
113 ZONE TYPE 2 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 28
114 ZONE TYPE 3 ALARM EVENT CODE 1 ............ numerical
Location 114 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details.
115 ZONE TYPE 3 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 28
