MODEL
3-5875
From General Electric. . . SSB-Single Side Band"SUPER BASE" (!) - a full feature Citizens Band
Transceiver base station for operation on all 40 AM channels, and 80 SSB (single sideband)channels, designedfor use in home
with 120-volt AC power. . . or truck and camper type of vehicles with 12-volt DC power. Phase Lock Loop (PLL) circuitry
electronically synthesizes all 40 channels. No additional crystals needed. Designed for the serious CB'er
...with top of the line
performance and loaded with features.
INDEX
. General Information . . . . . . . . . . . . . . . . . . . . . . . . . . .. 4
. Base Antenna Systems. . . . . . . . . . . . . . . . . . . . . . .. 4
. Mobile Antenna Systems. . . . . . . . . . . . . . . . . . . . . .. 5
. Supply the Power (120-volt AC or 12-volt DC) 5
. Operating Controls. . . . . . . . . . . . . . . . . . . . . . . . . . .. 6
. Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . .. 8
. "Q" Signals - "10 Codes" .. ... .... ... .. . ... .... 9
. Mobile Installation Instructions. . . . . . . . . . . . . . . . . . 10
. Schematic. . . . . . . . . . . . . . . . . . . . . . , . . . . . . . . . . . .. 11
. Service/Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
CB FEATURES
. PROGRAMMABLE ELECTRONIC DIGITAL CLOCK
. MANUAL POWER ON or OFF
. FUNCTION LIGHTS
. MODULATION/SWR METER
. RFIS METER
. SWR CALIBRATION control
. AWl LIGHT: Antenna Warning Light
. LED (light emitting diode) CHANNEL READOUT
. BRIGHTNESS control
. ON-THE-AIR light
. DUAL SPEED CLARIFIER controls
. RF GAIN control
. SQUELCHITONE/VOLUME controls
. SWITCHABLE ANL (automatic hois!"1limiter)
. NOISE BLANKER switch
. MICROPHONE POWER control
. SPEECH COMPRESSION switch
. 3-WAV PAlCB switch
. DUAL ANTENNA JACKS: to connect omni and beam type of
antennas or a dummy load.
. JACK FOR: PA SPEAKER, EXTERNAL SPEAKER, SCREW ON
TYPE MIC, AC AND DC POWER CORDS.
. WARNING: TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD,
DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. BEFORE
CONNECTING ANY WIRES OR INSTALLING YOUR CB, PLEASE
READ ALL INSTRUCTIONS.
