3
Antenna Assembly & Installation
1. Insert the Antenna Panel into one
of the grooved slots of the
Stand. Use a Thumb Screw to
attach the Antenna Panel
to the Stand.
2. Insert the Reflector Panel into the
other grooved slot of the Stand. Use
the other Thumb Screw to attach
the Reflector Panel to the Stand.
3. Place the assembled antenna in the desired location.
For best reception, you will want to face the Antenna Panel
towards the broadcast towers in your area. See
the Antenna Helpful Tips section for resources to help you
locate the broadcast towers in your area.
Note: The Antenna Panel may also be mounted to a wall
using the keyholes on the back of the antenna.
